Case Study: Rotating Equipment Reliability Using Optical Metrology

Dale Winterhoff, Manager, Technical Solutions, Flowserve DJ Winterhoff, Applications Engineer, Trilion

Description

Extreme thermal piping displacements were thought to be the root cause for the observed failures at a large refinery, namely 9 mechanical seal failures in 3 months. Optical Metrology methods were used to identify failure modes of critical service vacuum bottoms pumps. The testing involved the use of both photogrammetry and digital image correlation to show how the large thermal displacements of the piping contributed to the mechanical seal failures. A high speed optical metrology rotodynamic study was also performed to observe the effects of the piping displacements on the operation of the pump.
